Description
The 3HP Solar submersible pump 2200w in kenya is a high performance water pump designed for deep boreholes and demanding water supply systems. It operates fully submerged and uses solar energy to lift water to the surface with strong pressure and stable flow. This pump is ideal for farms, estates, and commercial applications where reliable water supply is required without depending on electricity. The 3hp solar submersible pump 2200w in kenya is built for users who need higher lifting capacity, strong output, and long term durability in Kenyan conditions.
Solar Pump System Overview
The 3hp solar submersible pump 2200w in kenya runs on DC power supplied by solar panels through an intelligent controller. It is designed for medium to deep boreholes and can operate efficiently during daylight hours. Pumps in this category are widely used in Kenya for irrigation, livestock watering, and large domestic water systems. They can also be integrated with hybrid systems if backup power is needed.
Key Features of 3HP Solar Submersible Pump 2200W in Kenya
3HP Equivalent 2200W Motor
The 3hp solar submersible pump 2200w in kenya is powered by a 2200 watt motor, approximately 3HP, designed for strong lifting performance and continuous operation. It provides high torque required for deep borehole pumping.
Maximum Head of 150 Meters
This pump can lift water up to 150 meters, making it suitable for deep boreholes and elevated storage systems. It performs well in areas where water tables are significantly below ground.
Steady Flow Rate Performance
Typical flow rate for this pump ranges between 5 to 8 cubic meters per hour depending on installation depth and solar input. This supports irrigation, livestock watering, and large scale domestic use.
High Voltage DC Operation
Most models operate within 150V to 280V DC systems, which improves efficiency and reduces power loss over long cable distances.
MPPT Controller Technology
The pump includes a controller with MPPT technology that maximizes solar energy usage and ensures stable operation even during low sunlight conditions.
Brushless DC Motor System
The 3hp solar submersible pump 2200w in kenya uses a brushless motor design that improves efficiency, reduces wear, and extends lifespan. This also lowers maintenance requirements.
Stainless Steel Construction
The pump is built with corrosion resistant stainless steel, ensuring durability in borehole water conditions.
Multi Stage Impeller Design
The pump uses multiple impellers to increase pressure and achieve higher head performance while maintaining steady flow.
Dry Run and Overload Protection
The controller includes safety features that stop the pump when water levels are low or when electrical faults occur.
Standard Borehole Compatibility
Most models are designed to fit 3 inch to 4 inch boreholes, making them suitable for common installations in Kenya.
Technical Specifications
| Feature | Specification |
|---|---|
| Power | 2200W (approx. 3HP) |
| Maximum Head | 150 meters |
| Flow Rate | 5 – 8 m³ per hour |
| Voltage | 150V – 280V DC |
| Controller | MPPT controller included |
| Pump Type | Solar submersible pump |
| Motor Type | Brushless DC motor |
| Material | Stainless steel |
| Pump Diameter | 3 inch – 4 inch |
| Installation | Vertical |
Recommended Solar Panel Setup
For the 3hp solar submersible pump 2200w in kenya, the typical solar configuration includes:
- 5 to 7 solar panels of 400W to 550W each
- Total solar capacity of about 2200W to 3500W
- Mounting structure and DC cables
- MPPT controller for system management
This setup ensures efficient operation during daylight hours.
Applications of 3HP Solar Submersible Pump 2200W in Kenya
The 3hp solar submersible pump 2200w in kenya is suitable for deep borehole water supply, irrigation systems, livestock watering, estates, schools, and rural water projects. It is also ideal for off grid locations where solar power is the main energy source.
Benefits of 3HP Solar Submersible Pump 2200W in Kenya
Suitable for Deep Boreholes
With a 150 meter head, this pump is designed for deep water sources.
Reliable Water Output
Provides steady flow for large scale water use.
Energy Efficient
Runs on solar power, reducing electricity costs.
Durable Construction
Built with strong materials for long service life.
Low Maintenance
Brushless motor reduces servicing needs.
Strong Performance
Delivers consistent pressure and flow.
Installation Guidelines
To install the 3hp solar submersible pump 2200w in kenya, lower the pump into the borehole to the correct depth and connect the delivery pipe. Install solar panels in a location with direct sunlight and connect them to the controller and pump. Ensure proper wiring and test the system before operation. Professional installation is recommended.
Maintenance Tips
Clean solar panels regularly, check electrical connections, avoid running the pump dry, inspect pipes and fittings, and service the pump when necessary.
Why Choose 3HP Solar Submersible Pump 2200W in Kenya
The 3hp solar submersible pump 2200w in kenya is a powerful solution for users who need reliable water pumping with strong lifting capacity. It is designed for Kenyan conditions and provides efficient performance for agricultural and domestic use. Its high head capability, steady flow rate, and durable construction make it a valuable long term investment.
Safety Guidelines
Ensure proper wiring, avoid handling electrical components with wet hands, secure solar panels properly, and switch off the system before servicing.
Frequently Asked Questions (FAQ)
What is the price of 3hp solar submersible pump 2200w in kenya
Prices in Kenya typically range from KSh 90,000 to KSh 180,000 depending on system configuration.
How deep can 3hp solar submersible pump 2200w in kenya pump water
It can pump water up to a maximum head of 150 meters.
What is the flow rate of 3hp solar 2 submersible pump 200w in kenya
It delivers about 5,000 to 8,000 litres per hour.
Is it suitable for irrigation
Yes, it is suitable for medium to large irrigation systems.
Does it come with solar panels
Some packages include solar panels, controller, and accessories.
Can it work without sunlight
No, it requires sunlight unless connected to a backup system.
